D 914 L3 (Agri)

Engine for agricultural machinery.
Air-cooled 3-cylinder naturally aspirated in-line-engine.
6-cylinder turbocharged, charge air cooled
Displacement: 1.1 liter/cylinder
Modular system with single cylinder units
Advanced injection and combustion system
Worldwide approved: more than 4.5 million engines in use
100 percent power take-off on the flywheel side and on the face end
Possibility of power take-off for hydraulic pumps and compressor
Only few maintenance points
Compact power-pack with low weight

Technical data
Emission norms EU IIIA, EU II, US T2, US T3
Number of cylinders 3
Bore 102 mm4 in
Stroke 132 mm5.2 in
Displacement 3.2 l195 cu in
Maximum nominal speed 2300 rpm
Power output 43 kW58 hp
at speeds 2300 rpm
Max. torque 204 Nm150 lb/ft
at speeds 1500 rpm
Min. idling speed 700 rpm
Specific fuel consumption 225 g/kWh0.37 lb/hph
Length 708 mm27.9 in
Width 666 mm26.2 in
Height 796 mm31.3 in
Weight 277 kg611 lb
Download data sheet (PDF-file)
