BF 4 M 2012 C

Modern water cooled 4-cylinder in-line engine.
Displacement 1.0 liters per cylinder
Compact design, high power-to-volume-ratio
Turbocharging and turbocharging with charge air cooling
High-pressure fuel injection up to 1600 bar
Electronic engine governor with diagnostic facilities with CAN-Bus optional
Three separate mounting options for gear-driven hydraulic pumps
Easy accessible service points on one engine side
User-friendly maintenance design
Wedge ribbed belt drive with automatic belt tensioner optional

Technical data
Emission norms EU II, US T2
Number of cylinders 4
Bore 101 mm4 in
Stroke 126 mm5 in
Displacement 4 l247 cu in
Maximum nominal speed 2500 rpm
Power output 103 kW138 hp
at speeds 2500 rpm
Max. torque 493 Nm364 lb/ft
at speeds 1500 rpm
Min. idling speed 800 rpm
Specific fuel consumption 202 g/kWh0.33 lb/hph
Length 847 mm33.3 in
Width 643 mm25.3 in
Height 835 mm32.9 in
Weight 391 kg862 lb
Download data sheet (PDF-file)
